Galvanized iron wire 8-24 BWG

Galvanized iron wire1.Materials: Q195 Iower carbon steel wire.2.Wire Diameters:from 4mm to 0.71mm (wire gauge 8 to 24)3.Feature: Strong breaking strength, softness, hard to rust.4.Tensile strength: 350-550N/mm2

Galvanized wire

1.Materials: Q195 Iower carbon steel wire.

2.Wire Diameters:from 4mm to 0.71mm (wire gauge 8# to 22#)

3.Feature: Strong breaking strength, softness, hard to rust.

4.Uses:Galvanized wire is mainly processed into coil wire, spool wire or big package wire.

Or further straightened and cut into cut wire and U type wire. Annealed wire is used as tie wire or baling wire in building, parks and daily binding.

5.Tensile strength: 350-550N/mm2

6.Production process:Processing with high quality low carbon steel /iron wire, through drawing and then annealed or galvanizing.

7,Packing.0.1-1kgs per roll,10roll per bundle;1-25kgs per coil;25-100kgs per coil. inner plastic film,then Woven cloth or Hessian cloth.

8.Our advantage:Our factory is specialized in producing hardware products, the main product is a variety of nails and wire, ligation, the wire contain complete specifications, reliable quality, ex-factory price, large supplies.

Size reference for Galvanized Wire

Wire Gauge

SWGin mm

BWG in mm

In Metric System mm


8#

4.06

4.19

4.00


9#

3.66

3.76

-


10#

3.25

3.40

3.50


11#

2.95

3.05

3.00


12#

2.64

2.77

2.80


13#

2.34

2.41

2.50


14#

2.03

2.11

-


15#

1.83

1.83

1.80


16#

1.63

1.65

1.65


17#

1.42

1.47

1.40


18#

1.22

1.25

1.20


19#

1.02

1.07

1.00


20#

0.91

0.89

0.90


21#

0.81

0.813

0.80


22#

0.71

0.711

0.70




Size:8-24BWG
Material:Q195 Lower carbon steel wire
Zinc coating:8-15G/M2;30-200G/M2
Tensile strength:350-550N/MM2
