Welded Wire Mesh Panel

WELDED WIRE MESH PANEL

WELDED WIRE MESH PANEL:

Materials:Stainless steel wire, Low carbon steel wire, Galvanized wire

 Style:

 Electro or Hot dipped galvanized after or before welding;

 Stainless steel wire welded wire mesh;

 PVC coated galvanized welded wire mesh;

Black wire/ without coated welded wire mesh.

Application:

Welded wire mesh is used in industry and agriculture, building, transportation and mining for all such purposes as Poultry houses, Egg baskets, Runway enclosures, Draining rack, Fruit drying screen, Fence.

Description:

It is made through the process of automation and sophisticated welding technique. The end product is level and flat, with sturdy structure and even strength throughout, the netting shows no wear and tear when cutting off a part or under a stress.

Opening

Wire Diameter

Inch

mm

1"x1"

25mmx25mm


2.5mm,2.0mm,1.8mm,1.6mm



2"x2"

50mmx50mm


2.5mm,2.0mm,1.8mm,1.6mm



2"x3"

50mmx70mm


6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm



2"x4"

50mmx100mm

6.0mm,5.0mm,4.0mm,3.0mm,2.0mm

2"x6"

50mmx150mm

6.0mm,5.0mm,4.0mm,3.0mm

2"x8"

50mmx200mm

6.0mm,5.0mm,4.0mm,3.0mm

3"x3"

75mmx75mm

6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm,1.6mm

3"x4"

75mmx100mm


6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm



4"x4"

100mmx100mm


6.0mm,5.0mm,4.0mm,3.0mm



5"x5"

125mmx125mm

6.0mm,5.0mm,4.0mm,3.0mm

6"x6"

150mmx150mm

6.0mm,5.0mm,4.0mm,3.0mm

Note: We can produce all kinds of size according to your requirements, Please contact us if any needs, thank you!







Height:0.5 meter to 3.0 meter
Length:0.5meter to 4 meter
Packing:Pallet
Mesh:20 mm to 200 mm
Diameter:1.0mm to 6.5 mm
